62"X, 34"Y, 32"Z, KASUGA QUANTUM Q-1500V,6000 RPM,FANUC 18M,40 ATC, 50 TAPER   Our stock number: 91511

62 X, 34 Y, 32 Z, KASUGA QUANTUM Q-1500V,6000 RPM,FANUC 18M,40 ATC, 50 TAPER

Click on picture below for larger version
62 X, 34 Y, 32 Z, KASUGA QUANTUM Q-1500V,6000 RPM,FANUC 18M,40 ATC, 50 TAPER


4th Axis Table Not Included. Used in large Facility - Machine in Very Good

Running Condition with no known issues.



Specification

Control........................ FANUC 18M
Maximum X-Axis (inches)........ 62"X
Maximum Y-Axis (inches)........ 34"
Maximum Z-Axis (inches)........ 32"
Talble X- Length (inches)...... 95" X 36"
Cutting Feed Rate X, Y & Z (ins) 0.1 - 390 IPM
Rapid Feed Rate X & Y (IPM).... 787 IPM
Rapid Feed Rate Z Axis (IPM)... 590 IPM
Spindle Taper.................. 50 TAPER
Spindle Speed (Maximum RPM).... 60 - 6000 RPM
Spindle Motor (HP)............. 30 HP
Tool Positions (ATC)........... 40 ATC
Weight (lbs) approx............ 33,000 LBS

EQUIPPED WITH:

THRU SPINDLE COOLANT
50 TAPER

EXCELLENT MACHINE
