DV-5 HARDINGE,1 1/16"ROUND,7/8" HEXAGON,3/4" SQ,3500 RPM,36"BED, HARDINGE TAPER   Our stock number: 93830

DV-5 HARDINGE,1 1/16 ROUND,7/8 HEXAGON,3/4 SQ,3500 RPM,36 BED, HARDINGE TAPER

Click on picture below for larger version
DV-5 HARDINGE,1 1/16 ROUND,7/8 HEXAGON,3/4 SQ,3500 RPM,36 BED, HARDINGE TAPERDV-5 HARDINGE,1 1/16 ROUND,7/8 HEXAGON,3/4 SQ,3500 RPM,36 BED, HARDINGE TAPERDV-5 HARDINGE,1 1/16 ROUND,7/8 HEXAGON,3/4 SQ,3500 RPM,36 BED, HARDINGE TAPERDV-5 HARDINGE,1 1/16 ROUND,7/8 HEXAGON,3/4 SQ,3500 RPM,36 BED, HARDINGE TAPER


MODEL # DV-59
Serial # DV-59-9009
Spindle capacity
Round 5C collets 1-1/16"
Hexagon 5C collets 7/8"
Square 5C collets 3/4"
Step chucks 1-1/16" to 6"
Jaw chucks 5"
Jaw chucks through spindle 1-5/32"
Spindle taper Hardinge taper
Length of bed 36"
Swing over bed 9"
Distance between centers 17"
Travel of top slide 4-1/4"
Travel of bottom slide 5"
Travel of tailstock spindle 3-1/2"
Tailstock spindle taper #2 Morse
Tool post capacity 3/8" x 1"
Infinitely variable spindle speed range 230 to 3,500 R.P.M.
Equipped With:
HARDINGE dovetail bed
HARDINGE X-Y compound
HARDINGE tailstock
Push button control for variable speed
Lever-type collet closer for type 5C collets
(32) Assorted size type 5C collets
1 H.P. 3/60/208 volt two-speed main drive reversing motor and electrical

controls

Approximate Weight: 1200 Lbs.
Approximate Dimensions: 68" L x 30'' W x 60'' H

VERY NICE MACHINE TOOL
