HLVH-H HARDINGE,11' X 18",1 1/4" SP,3000 RPM,5C COLLET CLOSER,VARIABLE SPEED   Our stock number: 92031

HLVH-H HARDINGE,11' X 18 ,1 1/4 SP,3000 RPM,5C COLLET CLOSER,VARIABLE SPEED

Click on picture below for larger version
HLVH-H HARDINGE,11' X 18 ,1 1/4 SP,3000 RPM,5C COLLET CLOSER,VARIABLE SPEEDHLVH-H HARDINGE,11' X 18 ,1 1/4 SP,3000 RPM,5C COLLET CLOSER,VARIABLE SPEED


To View Under Power Click on The link Below

https://youtu.be/QHcnZJZAtd4

GENERAL SPECIFICATIONS

Swing Over Bed: 11"
Swing Over Carriage: 9"
Swing Over Cross Slide: 5-3/4"
Distance Between Centers: 18"
Hole Through Spindle: 1-1/4"
Spindle Capacity, Round 5C Collets: 1-1/16"
Spindle Nose: Hardinge Tapered
Variable Spindle Speeds: 125 to 3000 RPM
Compound Slide Travel: 3"
Carriage Power Feed: 1/4" to 7" Per Minute
Tailstock Spindle Diameter: 1-3/8"
Tailstock Spindle Travel: 3-3/4"
Tailstock Spindle Taper: No. 2 Morse
Threads: (27) 11 to 108

EQUIPPED WITH

5c Collet Closer
Independent Electric Variable Power Feed Drive For Carriage and Cross Slide
Hardened and Precision Ground Steel Bed Ways
Coolant

Fully Functional and in Good Condition

Inspect Under Power in Our Lebanon NJ warehouse
