15" x 25" ECOTECH HZ64/630,BRAND NEW , 2006   Our stock number: 56824

15 x 25 ECOTECH HZ64/630,BRAND NEW , 2006


ECOTECH Model HZ64/630 15" X 25"
CAPACITY
WIDTH :15.75 in.
LENGTH :25.0 in.
HEIGHT :15.75 in. (w/out chuck) 11.8 in. (w/chuck)
MAXIMUM WORKLOAD :1,500 lbs.
NET WEIGHT :5512.5 lbs.
DIMENSIONS :103 x 78 x 73 in. (LxWxH)
WHEELHEAD
HORSE POWER :5.5 hp / 1,440 rpm
WHEEL SIZE :14.0 x 5.0 x 1.0 (ODxIDxW)
WHEEL SPEED :1,440 rpm
SURFACE SPEED :5316 spm
SPINDLE TAPER :1:5 taper
OIL RESERVOIR :n/a
SPINDLE BEARING :High Precision roller bearing
(VERTICAL MOVEMENT)
RAPID TRAVEL :20 ipm*
HANDWHEEL/REV :0.03937 in.
HANDWHEEL/DIV :.0002 in.
MAXIMUM TRAVEL RP :15.0 in.*
MAXIMUM TRAVEL HW :15.0 in.*
MINIMUM PRO DIV :.00008 - .0012 in.
SPINDLE TO TABLE :22.8 in.*
RAPID MOTOR :.5 hp / 1,800 rpm*
(HORIZONTAL MOVEMENT)
CROSS TRAVEL :15.0 in.
HANDWHEEL/REV :.1968 in.
HANDWHEEL/DIV :.0008 in.
CROSS FEED :.0002 min. picks stroke (intermittent)
:11.0 - 39.4 ipm (continuous) 59.0 ipm
CROSS MOTOR :.2 hp / 3,240 rpm*
WORKTABLE
FEED RANGE :19.7 - 984.2 ipm
MAXIMUM TRAVEL :29.6 in.
HANDWHEEL/REV :.275 in.*
TABLE CONFIGURATION :3 (T slots) 0.708 (width)
CHUCK SIZE :15.75 x 28.0 in. (WxL)
CHUCK POWER :110 volts 143 watts 1.3
TAILSTOCK
DRESSING :over-the-wheel (hydraulic)

ECOTECH MACHINERY, INC.
Model Attributes
HZ64/630
15" X 25"
HYDRAULIC SYSTEM
HORSE POWER :2.9 hp / 850 rpm
PRESSURE :198.8 psi
RESERVOIR :30 gal. 20 ISO viscosity
FLOW RATE :6.6 gpm
COOLANT SYSTEM
FLOW :202.6 gpm
HORSE POWER :.16 hp / 3,360 rpm
PRESSURE :43 psi
RESERVOIR :33 gal.
ACCURACIES (PERMISSIBLE DEVIATION)
FLATNESS :.0001/12.0 (overall)
PARALLELISM :.0005/25.0 (long) .0003/20 (short)
REPEATABILITY :.00004 in.
POWER VOLTAGE
VOLTAGE :220 volt 3 phase 60 Hz.
TOTAL KVA :15 kva
CURRENT AMPS :20 amp.
STANDARD EQUIPMENT
Electro Magnetic Chuck
Operation & Service Manual
Work Light (low voltage)
Special Wrench set
Leveling Wedges
Dresser Unit / Hydraulic over-the-wheel
Grinding Wheel w/hub
Complete Coolant System
Balancing Stand
U.S. Standard Electrics

CAPITAL INVESTMENT

MODEL HZ64/630 SADDLE TYPE HORIZONTAL SURFACE GRINDERSPRICE$36,300.00
