TABLE DIAMETER-------------------------46"
MAXIMUM SWING--------------------------58"
HEIGHT UNDER RAIL----------------------40"
VERTICAL TRAVEL OF TURRET--------------26"
MAIN MOTOR-----------------------------50 HP
TABLE SPEEDS-(20 SPEEDS)---------------6.8 TO 250 RPM
FEEDS----------------------------------.001 TO .250 IPR
APPROXIMATE WEIGHT---------------------38,000 LBS
APPROXIMATE DIMENSIONS--144" WIDE, 125" DEEP, 143" TALL
EQUIPPED WITH:
* 4 JAW HAND OPERATED CHUCK
* 5 SIDED POWER INDEXING TURRET
* CENTRAL REMOTE CONTROL PENDANT
CONDITION: APPEARS TO BE IN EXCELLENT CONDITION. INSPECT UNDER POWER IN PLANT
